Simplification is Our Innovation

QLI low intermodulation bayonet connectors make it easy to connect and disconnect

QLI

View Products
Quick Lock low Intermodulation high power connector, operating in the range DC-6 GHz
50 ohms / part series R184
QLI was launched in 2013 with similar performance as 7/16 but much easier to connect, smaller, lighter and cost effective.

Resources

Document Download
QLI Handout
QLI Catalog
View All Documents
Videos
QLI

Performances

Features:

  • Impedance : 50Ω
  • Frequency range : DC ~ 6 GHz
  • Very low intermodulation level (<-163dBc)
  • Durability : 100 mating cycles
  • Power rating : 1000 W @ 2 GHz
  • IP 67

Dimensions:

  • The outer diameter of the interface is approx 18.0mm
