Driving Innovation at Electronica: Radiall's Breakthrough Technologies
Every two years, exhibitors and industry professionals from all across the globe travel to Munich, Germany for Electronica. Electronica is the world’s leading trade fair for the electronics industry. It showcases the full spectrum of technologies, products and solutions, supporting advancements in areas like AI, electromobility and smart energy. With thousands of exhibitors and attendees, it fosters collaboration and innovation towards a sustainable, tech-driven future. Its goal is to lead the industry towards an “All Electric Society,” emphasizing sustainable and efficient technologies. Radiall attended the event and showcased our latest industry-advancing technologies.
Products on Display
IMP Family
IMP stands for Interconnect Micro-miniature Pressure. The latest IMP connectors and contacts provide innovative solutions which meet the needs of miniaturization and space constraints for board-to-board and board-to-modules applications. These new solderless products provide increased integration density, lighter interconnection and an easy implementation. They also offer a high degree of flexibility in the design of applications thanks to their modularity.
Features & Benefits
- Up to 65 GHz
- Low phase noise: -20 to -30 dB @ 1 kHz
- Insertion loss: ≤ 0.25 dB
- Crosstalk: -85 dB typ. @ 18GHz
- Low pitch: Ø 2.45 mm
- Board-to-Board distance: 1.41 mm to 16.5 mm
Contactless Carriers
As next generation of interconnect solutions, contactless connectors enable power and/or data transfer through any non-electrically conducting materials without physical link up to 1 kW. This product offering meets new design challenges by providing plug and play connectors. Imagine a waterproof and hermetic-sealed system to resist harsh environments and no more holes to transfer power and/or data with unlimited mating cycle.
CO15CAN Evaluation Kit
The CO15CAN kit allows you to test technology and discover the benefits of contactless power and data transmission through non-metallic material. Composed of a transmitter (Tx) and a receiver (Rx), it delivers 15 W at a variable distance of transmission 8 to 16 mm.
Features & Benefits
- Continuous power of 15 W
- Distance of transmission up to 16 mm
- Misalignment tolerance ±2 mm
- Data transmission
- Unlimited mating cycles
Quick Install
The Quick Install Radiall is a lightweight and quick install solution that reduces harness integration and maintenance time. It can also replace EN3545 due to the same panel cutout. This new connector provides high performances, weight reduction and tool-less panel mounting and locking. It received an “Airbus Supplier Innovation Award” in 2015, which recognized the product’s design, as well as Radiall’s innovation and ability to understand customer expectations.
Features & Benefits
- 15% lighter than the competition: It features a unique design made of composite material with a slim form factor that provides 15% weight savings compared to the legacy screwed connector. With an average weight of 45 g per mated pair, the weight reduction represents up to 20 kg for a typical aircraft.
- 80% installation time savings: A unique locking device system to ensure a quick, tool-less installation on the panel. A slide lock, which has already been mastered and qualified on other product ranges, to ensure instant manual mating of the harness connector
- A tool-less and fod-proof design: The Quick Install provides customers with a proven and reliable high performance solution that can replace the cable-to-cable, optical and equipment versions of EN3545.
- Self-inspection at mating: The slide technology features visual and audible indicators guarantee that the installation and mating tools are locked.
Quantum Components
Radiall’s quantum connectors are the result of years of research and development within our RF&I Business Units. These connectors ensure seamless signal transmission between different stages of a quantum system’s fridge chain, guaranteeing reliable performance even in the most extreme conditions. With our cryogenic-ready design and expertise in advanced connectivity technologies, these connectors are optimized for the precise demands of quantum environments.
Features & Benefits
- High performance cryogenic operation down to 10 millikelvin
- Multi-port capabilities with connectors supporting frequencies up to 18 GHz
- Reliable signal transmission across all fridge stages
- Cryogenic-ready design for extreme conditions
Radiall brings people together through technology. With creative ideas, streamlined manufacturing and leading-edge solutions, we impact the lives of people throughout the world. We’re able to connect with you–anywhere and anytime–because wherever technology lives, we’re there. To keep up with Radiall, connect with us on LinkedIn.
