Simplification is Our Innovation

SPDT Platinum SMA 20GHz Latching Self-cut-off Indicators 24Vdc TTL Positive common Diodes Pins terminals

R595463120 - Please contact Radiall for additional information

This part is RoHS Compliant, click here for more details.

Datasheets Download
Datasheets
SPDT Platinum SMA 20GHz Latching Self-cut-off Indicators 24Vdc TTL Positive common Diodes Pins terminals

R595463120

RF Configuration SPDT switches

Series PLATINUM

Terminated Non terminated

RF Connector SMA

Frequency Range DC - 20 GHz

Actuator Type Latching

Actuator Voltage 24

Number Ways 2

Indicator Circuit Yes

Electronic Option Self Cut-off

TTL Options With TTL driver

Actuator Terminal Solder pins

Click here to check availability
