SMPS M STRAIGHT RECEPTACLE SMT TYPE - EDGE CARD - LIMITED DETENT

RS03423000 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

Datasheets Download
3D.IGS
3D.STEP
SMPS M STRAIGHT RECEPTACLE SMT TYPE - EDGE CARD - LIMITED DETENT

RS03423000

Model PCB RECEPTACLE

Interface I SMP

Product Type CONNECTORS

Connector Type JACK

Space Standard ORBIX New Space

Max Frequency (GHz) 12

PCB Mounting SURFACE MOUNT

Center Contact Plating N2PGR

Body Plating N2PGR

Geometry EDGE CARD

Gender 1 MALE

Mating System SNAP-ON
