ESCC340200806B301

R143198661

Product Type: CONNECTORS

Gender 1: MALE

Cable Groups: SHF 8

Max Frequency (GHz): 18

Center Contact Plating: GOLD OVER NICKEL

ESCC parts: Yes

Body Plating: STAINLESS STEEL PASSIVATED

Geometry: RIGHT ANGLE

Cable Attachment: SOLDER TYPE

Mating System: SCREW-ON

Cable Standard: F1703-248

Connector Type: PLUG

Impedance (Ohm): 50

Interface I: TNC

Model: CABLE CONNECTOR
