SPDT Terminated Ramses SMA2.9 40GHz Normally open 12Vdc Diodes Internal loads Pins terminals

R585872230

RF Configuration: DP3T & Terminated SPDT switches

Series: RAMSES

Terminated: Terminated with internal load

RF Connector: SMA 2.9 (K)

Frequency Range: DC - 40 GHz

Actuator Type: Normally open

Actuator Voltage: 12

Number Ways: 2

Electronic Option: Suppression diodes

TTL Options: Without TTL driver

Actuator Terminal: Solder pins

OR
SPDT Terminated Ramses SMA2.9 40GHz Normally open 12Vdc Diodes Internal loads Pins terminals

R585872230 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information
