SPDT Terminated Ramses SMA 3GHz Failsafe Indicators 12Vdc TTL Diodes Internal loads Pins terminals

R585322300 - Please contact Radiall for additional information

This part is RoHS Compliant, click here for more details.

Datasheets Download
Datasheets
SPDT Terminated Ramses SMA 3GHz Failsafe Indicators 12Vdc TTL Diodes Internal loads Pins terminals

R585322300

RF Configuration DP3T & Terminated SPDT switches

Series RAMSES

Terminated Terminated with internal load

RF Connector SMA

Frequency Range DC - 3 GHz

Actuator Type Failsafe

Actuator Voltage 12

Number Ways 2

Indicator Circuit Yes

Electronic Option Suppression diodes

TTL Options With TTL driver

Actuator Terminal Solder pins
