SP6T Terminated Ramses 2.4mm 50GHz Normally open 28Vdc Pins Terminals

R574J03600 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

Datasheets Download
Datasheets
SP6T Terminated Ramses 2.4mm 50GHz Normally open 28Vdc Pins Terminals

R574J03600

RF Configuration SPnT multiport switches

Series RAMSES

Terminated Terminated with internal load

RF Connector 2.4mm

Frequency Range DC - 50 GHz

Actuator Type Normally open

Actuator Voltage 28

Number Ways 6

Electronic Option Without option

TTL Options Without TTL driver

Actuator Terminal Solder pins
