SP4T Terminated Ramses 2.4mm 50GHz Latching Self-cut-off Auto-reset Indicators 12Vdc BCD TTL Diodes D-sub connector

R574J92485 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

SP4T Terminated Ramses 2.4mm 50GHz Latching Self-cut-off Auto-reset Indicators 12Vdc BCD TTL Diodes D-sub connector

R574J92485

RF Configuration SPnT multiport switches

Series RAMSES

Terminated Terminated with internal load

RF Connector 2.4mm

Frequency Range DC - 50 GHz

Actuator Type Latching

Actuator Voltage 12

Number Ways 4

Indicator Circuit Yes

Electronic Option Self Cut-off + Automatic reset + Suppression diodes

TTL Options With TTL BCD driver

Actuator Terminal D-Sub

Click here to check availability
