SP3T Terminated Ramses SMA 26.5GHz Latching Self-cut-off Auto-reset Indicators 12Vdc TTL Diodes Pins Terminals

R574F92320 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

SP3T Terminated Ramses SMA 26.5GHz Latching Self-cut-off Auto-reset Indicators 12Vdc TTL Diodes Pins Terminals

R574F92320

RF Configuration SPnT multiport switches

Series RAMSES

Terminated Terminated with internal load

RF Connector SMA

Frequency Range DC - 26.5 GHz

Actuator Type Latching

Actuator Voltage 12

Number Ways 3

Indicator Circuit Yes

Electronic Option Self Cut-off + Automatic reset + Suppression diodes

TTL Options With TTL driver

Actuator Terminal Solder pins
