SP10T Terminated Ramses SMA 22GHz Latching Self-cut-off Auto-reset Indicators 28Vdc Diodes D-sub connector

R574F93005 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

Datasheets Download
Datasheets
SP10T Terminated Ramses SMA 22GHz Latching Self-cut-off Auto-reset Indicators 28Vdc Diodes D-sub connector

R574F93005

RF Configuration SPnT multiport switches

Series RAMSES

Terminated Terminated with internal load

RF Connector SMA

Frequency Range DC - 22 GHz

Actuator Type Latching

Actuator Voltage 28

Number Ways 10

Indicator Circuit Yes

Electronic Option Self Cut-off + Automatic reset + Suppression diodes

TTL Options Without TTL driver

Actuator Terminal D-Sub
