DPDT Ramses SMA 26.5GHz Failsafe 28Vdc Pins Terminals

R577F13002 - Please contact Radiall for additional information

This part is RoHS Compliant, click here for more details.

Click here to check for distribution inventory

Datasheets Download
Datasheets
DPDT Ramses SMA 26.5GHz Failsafe 28Vdc Pins Terminals

R577F13002

RF Configuration Transfer DPDT switches

Series RAMSES

RF Connector SMA

Frequency Range DC - 26.5 GHz

Actuator Type Failsafe

Actuator Voltage 28

Electronic Option Without option

TTL Options Without TTL driver

Actuator Terminal Solder pins
