DPDT Ramses 2.4mm 50GHz Latching 28Vdc Positive common Diodes Pins Terminals with bracket

R577J33040

RF Configuration: Transfer DPDT switches

Series: RAMSES

RF Connector: 2.4mm

Frequency Range: DC - 50 GHz

Actuator Type: Latching

Actuator Voltage: 28

Electronic Option: Positive common + Suppression diodes

TTL Options: Without TTL driver

Actuator Terminal: Solder pins

Specific Feature: Mounting bracket

OR
DPDT Ramses 2.4mm 50GHz Latching 28Vdc Positive common Diodes Pins Terminals with bracket

R577J33040 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information
