SMA / STRAIGHT PLUG CRIMP TYPE CABLE .141

R125055941

Brand: RADIALL

Product Type: Connectors

Interface I: SMA

Model: CABLE CONNECTOR

Max Frequency (GHz): 26.5

Impedance (Ohm): 50

Geometry: STRAIGHT

Connector Type: PLUG

Gender 1: MALE

Cable Standard: KS 2, RG 402

Cable Attachment: CRIMP TYPE

Cable Groups: .141''/50 SR

Mating System: SCREW-ON

Center Contact Plating: GOLD 1.3 OVER NICKEL 2

Body Plating: PASSIVATED

OR
SMA / STRAIGHT PLUG CRIMP TYPE CABLE .141

R125055941 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information

Datasheets
Datasheets
3D.IGS
3D.STEP
Search Tip
Remove spaces, dashes, and periods. Enter the first several characters to obtain all values within a product family (ex: R125) or enter a complete part number to target a specific result (ex: R125069000).
