HN / STRAIGHT PLUG SHOULDERED CENTER CONTACT CLAMP TYPE CABLE 10+11/50
R176021000 - Please contact Radiall for additional information
This part is RoHS Compliant, click here for more details.
R176021000
Brand RADIALL
Product Type Connectors
Interface I HN
Model CABLE CONNECTOR
Max Frequency (GHz) 3
Impedance (Ohm) 50
Geometry STRAIGHT
Connector Type PLUG
Gender 1 MALE
Cable Standard KX 13, KX 4, RG 165, RG 213, RG 214, RG 225
Cable Attachment CLAMP TYPE
Cable Groups 10/50 S, 11/50 D
Mating System SCREW-ON
Center Contact Plating SILVER 5
Body Plating NICKEL 2
