BNC / STRAIGHT JACK CRIMP TYPE CABLE 5/50 S

R141237161

Brand: RADIALL

Product Type: Connectors

Interface I: BNC

Model: CABLE CONNECTOR

Max Frequency (GHz): 1.5

Impedance (Ohm): 50

Geometry: STRAIGHT

Connector Type: JACK

Gender 1: FEMALE

Cable Standard: KX 15, RG 141, RG 58

Cable Attachment: CRIMP TYPE, FULL CRIMP TYPE

Cable Groups: 5/50 S

Mating System: BAYONET

Center Contact Plating: GOLD 0.5 OVER NICKEL 2

Body Plating: NICKEL 2

Click here to check availability
OR
BNC / STRAIGHT JACK CRIMP TYPE CABLE 5/50 S

R141237161 - Please contact Radiall for additional information

This part is RoHS Compliant, click here for more details.
