OCTIS™

Simplification is Our Innovation

OCTIS: Outdoor Connector Transceiver Inside System

OCTIS™

View Products

OCTIS: Outdoor Connector Transceiver Inside System

Specifically designed to address the interconnect challenges associated with the deployment of 4G+, LTE+ and future 5G in the Telecom market, OCTIS provides a robust I/O solution that can operate in outdoor and harsh environments.

OCTIS is the perfect solution for outdoor small cell and next generation RRU/RRH projects that support broadband Ethernet and outdoor microwave network units.

Resources

Document	Download
OCTIS™ Handout
OCTIS™ Catalog

View All Documents

Videos
OCTIS™ RJ45
OCTIS™ with Crimp Contacts
OCTIS™ Power Screw Unshielded
OCTIS™ Universal Plug
OCTIS™ Signal Plug Kit
OCTIS™ Plug Kit Combo
OCTIS™ SFP
OCTIS™ Flip Instructions
OCTIS™ Wide Universal
OCTIS™ Power Screw Shielded

Performances

High Density: pitch 26mm
Small form factor: length to panel < 100mm
SFP/SFP+ transceiver inside plug with optimized heat dissipation
EMI shielding
Lightning protection: up to 15 KAmps
Blind mate
Field installable
Secured connection with locking feature

Multi-standard outdoor solution:

SFP/SFP+ optical (with LC duplex)
RJ45 ethernet signal (cat5e or cat6)
Power supply (AC/DC)
High data rate signal, POE+
Hybrid of power and signal

Ruggedized weatherproof design:

Durability: 100 mating cycles
Cable tensile load : up to 200N
IP67 sealing protection
720H Salt Spray + SO2 (IEC 21207 method B)
Temperature range: -40°C to +85°C
Connector keying and color coding to prevent improper connection

IEC and GR Telcordia international standards full compliant
