SPPC-SB-PS-EU-L-M12-T4-PM
VS398921 - Please contact Radiall for additional information
For REACH and RoHS status, click here for additional information.
VS398921
Application Power supply
Series SPPC-SB
Connector Type Distribution Box, Sequential Box
Number of Contacts 5
Drain Panel Source Connectors with rubber caps
Contact Termination M12 Threaded post, brass contacts
Voltage Rating 1000 V
Current Rating 500 A
Color European
Sealing Protection IP65/67
Temperature Range -30°/+85°C
Mating Cycles 500
