Terminated 4 ports bypass Ramses 2.4mm 50GHz Failsafe Indicators 12Vdc External loads Pins terminals

R585J22600 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

Click here to check for distribution inventory

Datasheets Download
Datasheets
Terminated 4 ports bypass Ramses 2.4mm 50GHz Failsafe Indicators 12Vdc External loads Pins terminals

R585J22600

RF Configuration DP3T & Terminated SPDT switches

Series RAMSES

Terminated Terminated with external load

RF Connector 2.4mm

Frequency Range DC - 50 GHz

Actuator Type Failsafe

Actuator Voltage 12

Number Ways 4

Indicator Circuit Yes

Electronic Option Without option

TTL Options Without TTL driver

Actuator Terminal Solder pins
