SMP / STRAIGHT MALE EDGE CARD RECEPTACLE SMT LIMITED DETENT

R222423320

Brand: RADIALL

Product Type: Connectors

Interface I: SMP

Model: PCB RECEPTACLE

Max Frequency (GHz): 12

Impedance (Ohm): 50

Geometry: EDGE CARD

PCB Mounting: SMT

Connector Type: JACK

Gender 1: MALE

Mating System: SNAP-ON

Center Contact Plating: GOLD 1.3 OVER NICKEL 1.3

Body Plating: GOLD 1.3 OVER NICKEL 2

OR
SMP / STRAIGHT MALE EDGE CARD RECEPTACLE SMT LIMITED DETENT

R222423320 - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information

Datasheets
Datasheets
3D.IGS
3D.STEP
