DPDT Ramses Low PIM N 12.4GHz Latching Indicators 28Vdc Positive common Diodes Pins Terminals with bracket

R577143040LP - Please contact Radiall for additional information

For REACH and RoHS status, click here for additional information.

Click here to check for distribution inventory

Datasheets Download
Datasheets
DPDT Ramses Low PIM N 12.4GHz Latching Indicators 28Vdc Positive common Diodes Pins Terminals with bracket

R577143040LP

RF Configuration Transfer DPDT switches

Series Low PIM, RAMSES

RF Connector N

Frequency Range DC - 12.4 GHz

Actuator Type Latching

Actuator Voltage 28

Indicator Circuit Yes

Electronic Option Positive common + Suppression diodes

TTL Options Without TTL driver

Actuator Terminal Solder pins

Specific Feature Low PIM
